中央驾驶舱补助帆桁巡游帆船游艇(甲板会客区轻质龙骨巡航帆船)
产品图片
重要参数
    用途 巡游
    甲板布局 甲板会客区, 中央驾驶舱
    帆缆索具 补助帆桁
    全部长度 16.18 m (53'01")
    宽度 15'03" (4.66 m)
    吃水深度 6'02" (1.89 m)
    位置 39,500 lb (17,916.9 kg)
    发动机功率 60 ch (60 hp)
    燃料容量 200 gal

产品简介

以它分享它的名字的美丽的热带花命名, Kanter九重葛54是一条惊人快速,难以置信地时髦的近海,长途巡航的游艇。 在她的速度和巨大稳定之外,九重葛54也吹嘘卓越的安全和对游艇九重葛系列是独特的丰富的舒适的水平。

九重葛54's例外表现是她的感人地轻的位移的结果并且她的积极地球状的船骨和任意水石碴。

船骨比与传统船骨的实际情形例外稳定的是省略地球状的浅滩草稿船骨的最新的版本并且安置低石碴。 她的轻量级和高技术船骨的组合使九重葛54运载入产生真实地令人喜欢的航行速度的风速。

著名的海军建筑师Chuck Paine从单独的近海赛跑的概念获得了九重葛54的设计并且相信游艇应该是足够快速地逃脱风暴,足够强通过一个航行。 使用高强度,要实现这个目标,九重葛54被修造,焊接-熔合建筑,与联合的船身、甲板和超结构。

而船身设计在脚底之下创造水和燃料的缺一不可的储存箱,有效地创造双重底部建筑和安全,二焊接了,水密铝隔框做九重葛54一种难以置信地强和安全工艺。

英文介绍

Named after the beautiful tropical flowers with which it shares its name, the Kanter Bougainvillaea 54 is a stunningly fast, incredibly stylish off-shore, long-distance cruising yacht. Beyond her speed and great stability, the Bougainvillaea 54 also boasts remarkable safety and a level of opulent comfort that is unique to the Bougainvillaea series of yachts.

The Bougainvillaea 54’s exceptional performance is the result of her impressively light displacement as well as her aggressively bulbed keel and optional water ballast.

The keel is the latest version of the elliptically bulbed shoal draft keel and places the ballast far lower than would be the case with a traditional keel for exceptional stability. The combination of her light weight and high-tech keel enables the Bougainvillaea 54 to be carried up into wind speeds that yield truly exhilarating sailing speeds.

Noted naval architect Chuck Paine derived the design of the Bougainvillaea 54 from single-handed offshore racing concepts and believes that a yacht should be fast enough to outrun a storm yet strong enough to sail through one. To accomplish this goal, the Bougainvillaea 54 is built using high-strength, welded -alloy construction, with a combined hull, deck and superstructure.

Two welded, watertight aluminum bulkheads make the Bougainvillaea 54 an incredibly strong and safe craft, while the hull design creates integral storage tanks for water and fuel below the sole, effectively creating double-bottom construction and safety.
