产品简介

GW13/310气动角钢抛光和研磨工具是表面和清漆加工的理想选择。它被用于汽车工业、模具制造、机械制造和塑料工业。

由于优化了杠杆阀，实现了无级调速。由于符合人体工程学的手柄，改善了触觉和冷绝缘，使工作无疲劳感。短小的设计允许在难以进入的地方工作。运行平稳，振动小。卓越的重量-功率比。低空气消耗值。

功率: - 130 W

速度: - 3100 min-1

轮子直径: - max.50毫米

卡盘: - M14

启动。 - 阀杆

长度: - 221 mm

高度: - 48 mm

排气： - 后侧

重量: - 0.5 公斤

进气口: - G 1/8" 。

推荐的软管直径: - 6 mm

空气消耗量: - 4.0 l/s

声压级: - 76 dB(A)

振动： - < 2.5 m/s2

电流: - 气动

P_Max.最大压力: - 6.3 bar

英文介绍

The pneumatic angle polishing and grinding tool GW13/310 is ideal for surface and varnish processing. Is is used in automotive industry, mould making, machine building and plasctics industry.

Stepless speed control due to optimized lever valve. Improved haptic and cold insulation thanks to ergonomic grip for fatigue-free working. The short and small design allows working in places difficult to access. Smooth running and low vibration. Excellent weight-power ratio. Low air consumption values.

Power: - 130 W

Speed: - 3100 min-1

Wheel Ø: - max. 50 mm

Chuck: - M14

Start: - Valve lever

Length: - 221 mm

Height: - 48 mm

Exhaust air: - back side

Weight: - 0.5 kg

Inlet air connection: - G 1/8"

Recommended hose Ø: - 6 mm

Air consumption: - 4.0 l/s

Sound pressure level: - 76 dB(A)

Vibration: - < 2.5 m/s2

Current: - Pneumatic

P_Max. Betriebsdruck: - 6.3 bar
