30英尺多功能开放式补助帆桁竞赛帆船(甲板布局简单高效)
产品图片
重要参数
    用途 竞赛
    甲板布局 开放式
    帆缆索具 补助帆桁
    全部长度 9.15 m (30'00")

产品简介

一艘专门针对亚盘比赛的纯正赛艇。

我们的想法是将这种设计开放给尽可能多级别的比赛:近岸和离岸,全员和双手,ORCI国际赛事(C级),ORCI运动艇分部赛事,以及IRC锦标赛,为什么不参加HP30赛事。

多功能性

Corsa 915最重要的特点是多功能性。船体线条的设计是为了在直立时尽可能的干爽,但在后跟时又有强大的力量,低自由板与倒角的船舷线有助于减少空气阻力,但仍然保持足够的内部空间,以便在离岸时更容易在下面生活。

甲板布局

甲板布局简单而高效,既适用于全员航行,也适用于双人航行。横向副翼轨道的设计不仅可以在逆风的VMG航行中进行微调,也可以在航行中进行微调。

航行计划

帆的设计并不极端,但它的设计是为了在任何情况下都能提供合适的动力。大副帆在轻空气条件下,特别是在加速时有很大帮助,而相当长的J帆则允许设置多个头帆。该船配备了一个可伸缩的船首桅杆,可以固定和稳定近海比赛用的摇杆,以便携带帆。

技术规格

全长9.15米

光束最大米数3,00

深度2.00米

排水量 公斤 2.000

ORC/IRC等级600/1.050。

英文介绍

A pure racing boat specifically addressed to handicap racing

the idea was to open this design to as many levels of racing as possible: inshore and offshore, full crew and double handed, ORCi international events (Class C), ORCi Sportboat division events and also IRC championships and why not HP30 events.

Versatility

the most relevant feature of the Corsa 915 is versatility. The hull lines are designed to be as dry as possible when upright but powerful when heeled, low freeboards with chamfered sheerline help in reducing aero drag but still maintaining enough room inside in order to make life easier down below during offshores.

Deck layout

the deck layout is simple but efficient both in fully crewed situations but also for double handed sailing. Transversal jib tracks are designed to allow fine trimming not only during upwind VMG sailing but also on a reach.

Sail Plan

the sail plan is not extreme in any sense but it is designed to deliver the right amount of power for any situation. The large jibs help in light air conditions especially when accelerating and the quite long J will permit multiple headsails set ups. The boat is fitted with a retractable bowsprit that can be fixed and stabilized with a bobstay for offshore racing in order to carry reaching sails.

Technical Specifications

Lenght over all meters 9,15

Beam max meters 3,00

Depth meters 2,00

Displacement kg 2.000

ORC / IRC Rating 600 / 1.050
