升降龙骨巡游帆船(脚踏泵低功率舷外机船)
产品图片

重要参数
    用途 巡游
    附件 升降龙骨
    全部长度 10.24 m (33'07")
    宽度 2.5 m (8'02")
    位置 2.4 t, 3.6 t (2.65 us ton)

产品简介

小学我亲爱的华生.....,他是个医生....。这艘船的名字是一个典故,但同时也是其概念的合理性。它的确是一艘基本的帆船。但在这明显的简单之下,却隐藏着一个令人印象深刻、舒适、宜居的船。简单地说,有所有它是必要的,没有多余的。所有的功能,都是为使用而考虑的,毫无顾虑。一艘非常好的帆船能够载着你在世界的尽头,到细沙上的海滩,像你一样带着你在周末的时候在岛屿上转一圈。

规格 - 描述

这艘船在其表面的简单性下,聚集了一定数量的特点,使其非常有吸引力。例如,龙骨是可升降的,两个方向舵使其可以在任何地方保持平衡。最大的横梁授权的道路大小,也使它与一个合理的动力车辆的牵引兼容的位移。驾驶舱限于腿部的空间,带来了可观的内部容积。甲板梁下的高度是2米,就像除了铺位的长度。在船上,不是电线,不是电池,简单的LED灯桩上的照明。不使用电动水泵。一个简单的脚踏泵就够了。不是船上的任何一个发动机,而是一个低功率的舷外机船,安排在休息室或在其椅子上的站。简单性保证了航行无忧。建设可以做出来的胶合板或铝。当然,如果你愿意,它可以配备在一个更传统的方式。

英文介绍

Elementary my dear Watson ..... who was a doctor…. The name of this boat is an allusion, but is at the same time the justification of its concept. It is indeed an elementary sailing ship. But under this apparent simplicity is hiding place a impressive, comfortable, livable boat. Simply, there is all that it is necessary, without superfluity. All functional, is thought for a use without concern. A very good sailing ship able to carry out you at the end of the world, to beach on a fine sand, like you to take along to make a turn in the islands the one weekend time.

Specifications: - Description

Under its apparent simplicity, this boat gathers a certain number of characteristics which make it very attractive. The keel for example is liftable and the two rudders make it possible to be posed in balance anywhere. The maximum beam authorizes the road size as also the displacement which makes it compatible with a traction by a reasonable vehicle of power. The cockpit limited to the space of the legs brings an appreciable interior volume. The height under deck-beams is of 2m, like besides the length of the berths. On board, not of wire, not of batteries, simply of lightings with LED on piles. Not either of electric pump for water. A simple pump with foot is enough. Not either of engine in-board, but an outboard motor boat of low power arranged in the lazaret or at station on its chair. Simplicity guarantees navigations without concern. Construction can be done out of plywood or aluminum. And of course, if you wish it, it can be equipped in a more traditional way.
